Routing and terminating the VF cables 6-27
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 6-5 (continued)
Connecting the VF cable pairs 601–1200 to 710 or 3M MS2 DPM connectors with cross-connect
Figure 6-12
Extend binder groups across the swing frame support bars
—continued—
Extended binder groups across
horizontal support bars
To Next Page
