6-40 Routing and terminating the VF cables
AccessNode 323-3001-210 Issue 1.0
Procedure 6-8 (continued)
Connecting the outside plant cable pairs to 710 or 3M MS2 DPM connectors without
cross-connect
Table 6-4 (pair count top to bottom) outlines each binder group and its
respective swing frame support bar position.
—continued—
Table 6-4
Routing binder groups across the swing frame (pair count top to bottom)
Support
bar
VF line
number
Column 1
binder group
Distribution
Pairs 601–1200
Column 2
SPC cables
Feeder
Pairs 1–600
Column 3
binder group
Distribution
Pairs 1–600
1 1–25 White / Blue 1–25 White / Blue
1 26–50 White / Orange 26–50 White / Orange
2 51–75 White / Green 51–75 White / Green
2 76–96 White / Brown 76–100 White / Brown
3 97–121 White / Slate 101–125 White / Slate
3 122–146 Red / Blue 126–150 Red / Blue
4 147–171 Red / Orange 151–175 Red / Orange
4 172–192 Red / Green 176–200 Red / Green
5 193–217 Red / Brown 201–225 Red / Brown
5 218–242 Red / Slate 226–250 Red / Slate
6 243–267 Black / Blue 251–275 Black / Blue
6 368–288 Black / Orange 276–300 Black / Orange
7 289–313 Black / Green 301–325 Black / Green
7 314–338 Black / Brown 326–350 Black / Brown
8 339–363 Black / Slate 351–375 Black / Slate
8 364–384 Yellow / Blue 376–400 Yellow / Blue
9 385–409 Yellow / Orange 401–425 Yellow / Orange
9 410–434 Yellow / Green 426–450 Yellow / Green
10 435–459 Yellow / Brown 451–475 Yellow / Brown
10 460–480 Yellow / Slate 476–500 Yellow / Slate
11 481–505 Violet / Blue 501–525 Violet / Blue
11 506–530 Violet / Orange 526–550 Violet / Orange
12 531–555 Violet / Green 551–575 Violet / Green
12 556–576 Violet / Brown 576–600 Violet / Brown
