Routing and splicing the fiber cable 7-35
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 7-4 (continued)
Routing fiber to the ABM when no FPP is installed
Special tools required
There are no special tools required for completing this procedure.
Materials required
• split flex tubing, approximately 30 ft (9.12 m)
• fiber patch cords or pigtails (see Table 7-9, Table 7-10 on page 7-36 and
Table 7-11 on page 7-36)
Table 7-9 lists the ordering information for optical patch cords.
Note: Ensure that the type of connector on the patchcord is compatible
with the type of connectors on the OC-3 or OC-12 card in the ABM shelf
and with the type of connectors in the FPP.
—continued—
Table 7-9
Optical patch cords
PEC Length (meters) Length (feet) Connector type
NT7E46AB 10 32.8 Biconic-biconic
NT7E46AC 15 49.2
NT7E46AD 20 65.6
NT7E46AE 30 98.4
NT7E46BB 10 32.8 FC-FC
NT7E46BC 15 49.2
NT7E46BD 20 65.6
NT7E46BE 30 98.4
NT7E46CB 10 32.8 ST-ST
NT7E46CC 15 49.2
NT7E46CD 20 65.6
NT7E46CE 30 98.4
NT7E46FB 10 32.8 SC-SC
NT7E46FC 15 49.2
NT7E46FD 20 65.6
NT7E46FE 30 98.4
