8-4 Provisioning the external alarms
AccessNode 323-3001-210 Issue 1.0
Procedure 8-1 (continued)
Provisioning and verifying the external alarms
Action
Step Action
1 Provision the E2A parallel telemetry alarms through the AccessNode
software according to the Nortel Networks recommended provisioning shown
in Table 8-1.
Note 1:
The E2A provisionable alarms may be set according to standard local
customer practices. Nortel Networks recommends that the alarms are
provisioned in the software as per that shown in Table 8-1.
Note 2:
Refer to
System Administration Procedures
, 323-3001-302, in
Operations, Administration, & Provisioning
, Volume 4A, for AccessNode
alarm provisioning.
Note 3:
Alarm testing will be done during the execution of the procedures in
Commissioning and Testing,
Volume 3.
—end—
Table 8-1
Provisionable E2A alarm definitions
Provisionable
E2A alarms
Scan
point Definition
Alarm
severity
Signal
name
Wire-wrap
block pin
AC ALM 1 AC Fail Minor XE2AR01 1
AC ALM 1 AC Fail Minor XE2AR01 1
LVA 2 Low Voltage Major XE2AR02 3
ACO 3 <Reserved> N/A XE2AR03 4
DOALM 4 Door Ajar Major XE2AR04 6
LTMP 5 Low Temperature Major XE2AR05 7
FA 6 Fuse Alarm
(BBP Circuit Breakers)
Major XE2AR06 9
MIN 7 RFA Minor Minor XE2AR07 10
MAJ 8 RFA Major Major XE2AR08 12
RPTR FA 9 Repeater Fuse Alarm Major XE2AR09 13
RPTR LOS 10 Repeater Loss of Signal (LOS) Major XE2AR010 15
RPTR ERR 11 Repeater Error (ERR) Major XE2AR011 16
LGND Logic Ground LGND 2, 5, 8, 11, 14,
17,18
