10-8 Adjusting the rectifier and the dc distribution shelf
AccessNode 323-3001-210 Issue 1.0
Procedure 10-1 (continued)
Powering the rectifier(s)
Figure 10-3
AC power pedestal load center detail
FW-15166
—continued—
Front view
(Shown with
doors removed)
NORMAL
SERVICE
DISCONNECT
AC POWER
EMERGENCY
CB5
CB6
CB1
CB2
CB3MAIN
CB4
FW-15166
