10-10 Adjusting the rectifier and the dc distribution shelf
AccessNode 323-3001-210 Issue 1.0
Procedure 10-1 (continued)
Powering the rectifier(s)
Figure 10-4
MPR25 (NT5C06) rectifier faceplate
FW-11099
—end—
EQL
FLT
FAN
HVSD
ON/RFA
OUTPUT
V+
V-
3/4A 250V
LOAD
AC
DC
F1
FW-11099
Equalizer/float
switch and adjust
Fan alarm
HVSD adjust
Rectifier On/fail
Circuit breakers
Filter
option
Inrush current
limit fuse
Current
meter
Test
points
