12-18 Cabinet maintenance operations
AccessNode 323-3001-210 Issue 1.0
Procedure 12-2 (continued)
Replacing the rectifier
Step Action
14 Perform the following steps as per the RFA LED indication on the rectifiers:
15 Continue the rectifier adjustments with Procedure 12-3 on page 12-19.
—end—
Table 12-7
RFA LED indication recovery steps
If the RFA LED indicates Then perform these steps
Red after 15 seconds • Verify the in-rush fuse.
• If the fuse is faulty replace the fuse and go to
step 13.
• If the fuse is good reinsert the fuse.
• Go to step 5.
Green • Go to step 15.
