Cabinet maintenance operations 12-49

AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0

Procedure 12-15 (continued)

Replacing the equipment fan shelves

Figure 12-13

Equipment fan shelf locations

FW-15239

—continued—

CDS 5

Cabinet

door

Shelf

spacer

Air

director

CDS 4

Fan

shelf (1)

CDS 3

CDS 2

CDS 1

CDS 7

CDS 6

ABM shelf

Fan shelf (2)

LCAP

BIP

FW-15239
