Cabinet and equipment wiring and cabling 13-21

AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0

Figure 13-13

DC distribution shelf to rectiﬁer shelf alarm wiring

FW-15191

DC shelf Rectifier shelf 1

PWR

SHLF

PWR

SHLF

Rectifier shelf 2

Rectifer 1

Rectifer 2

Rectifer 3

Rectifer 2

Rectifer 1

Rectifer 3

FW-15191
