Nortel SONET AccessNode 800A Series User Manual

Cabinet and equipment wiring and cabling 13-45
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Table 13-11 lists the VT and D link mapping to the CDS.
Table 13-11
SIR connector VT and D link mapping to CDS
Connector VT &D link Line drawer Line shelf Line number
J01 1A 1 CDS1 1- 48
J02 1B 1 CDS1 1- 48
J01 2A 2 CDS1 49- 96
J02 2B 2 CDS1 49- 96
J03 3A 1 CDS2 101-148
J04 3B 1 CDS2 101-148
J03 4A 2 CDS2 149-196
J04 4B 2 CDS2 149-196
J05 5A 1 CDS3 201-248
J06 5B 1 CDS3 201-248
J05 6A 2 CDS3 249-296
J06 6B 2 CDS3 249-296
J07 7A 1 CDS4 301-348
J08 7B 1 CDS4 301-348
J07 8A 2 CDS4 349-396
J08 8B 2 CDS4 349-396
J09 9A 1 CDS5 401-448
J10 9B 1 CDS5 401-448
J09 10A 2 CDS5 449-496
J10 10B 2 CDS5 449-496
J11 11A 1 CDS6 501-548
J12 11B 1 CDS6 501-548
J11 12A 2 CDS6 549-596
J12 12B 2 CDS6 549-596
J13 13A 1 CDS7 601-648
J14 13B 1 CDS7 601-648
J13 14A 2 CDS7 649-696
J14 14B 2 CDS7 649-696
