Cabinet and equipment wiring and cabling 13-57
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
DS1-11 I/P
working
DTW11+(T) 26 V-S AINT25 BOUTT25 OUTT11 57 P V-S
DTW11- (R) 41 S-V AINR25 BOUTR25 OUTR11 25 S-V
DS1-12 I/P
working
DTW12+(T) 27 W-BL AINT26 BOUTT26 OUTT12 58 P W-BL
DTW12- (R) 42 BL-W AINR26 BOUTR26 OUTR12 26 BL-W
DS1-13 I/P
working
DTW13+(T) 28 W-O AINT27 BOUTT27 OUTT13 59 P W-O
DTW13- (R) 43 O-W AINR27 BOUTR27 OUTR13 27 O-W
DS1-14 I/P
working
DTW14- (T) 29 W-G AINR28 BOUTR28 OUTR14 60 W-G
DTW14- (R) 44 G-W AINR28 BOUTR28 OUTR14 28 G-W
—end—
Table 13-13 (continued)
DS1 IN - repeater OUT connections (I/O card 2)
DS1 Input
cable
DSX IN-OUT
cross-connect
Repeater
DSX cable
Signal
type
Signal
name
Cable
pin# Color
Signal
name
Signal
name
Signal
name
Cable
pin# Color
