Cabinet and equipment wiring and cabling 13-59
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
DS1-11 O/P
working
DRW11+(T) 26 BK-BL AOUTT11 BINT11 INT11 43 P BK-BL
DRW11- (R) 41 BL-BK AOUTR11 BINR11 INR11 11 BL-BK
DS1-12 O/P
working
DRW12+(T) 27 BK-O AOUTT12 BINT12 INT12 44 P BK-O
DRW12- (R) 42 O-BK AOUTR12 BINR12 INR12 12 O-BK
DS1-13 O/P
working
DRW13+(T) 28 BK-G AOUTT13 BINT13 INT13 45 P BK-G
DRW13- 43 G-BK AOUTR13 BINR13 INR13 13 G-BK
DS1-14 O/P
working
DRW14+(T) 29 BK-BR AOUTT14 BINT14 INT14 46 P BK-BR
DRW14- 44 BR-BK AOUTR14 BINR14 INR14 14 BR-BK
—end—
Table 13-14 (continued)
DS1 OUT - repeater IN connections (I/O card 1)
DS1 Output
cable
DSX IN-OUT
cross-connect
Repeater
DSX cable
Signal
type
Signal
name
Cable
pin# Color
Signal
name
Signal
name
Signal
name
Cable
pin# Color
