Cabinet and equipment wiring and cabling 13-71
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Table 13-17 shows the ABM cabling and wiring for the S800A cabinet.
Table 13-17
ABM cabling and wiring
From
Location Terminal Identification
To
Location Terminal
VD &T Link (side interconnect right)
ABM CDS 1A (J01) NT1W82DC CDS 1 CDS A
ABM CDS 1B (J02) NT1W82DC CDS 1 CDS B
ABM CDS 2A (J03) NT1W82DD CDS 2 CDS A
ABM CDS 2B (J04) NT1W82DD CDS 2 CDS B
ABM CDS 3A (J05) NT1W82DE CDS 3 CDS A
ABM CDS 3B (J06) NT1W82DE CDS 3 CDS B
ABM CDS 4A (J07) NT1W82DF CDS 4 CDS A
ABM CDS 4B (J08) NT1W82DF CDS 4 CDS B
ABM CDS 5A (J09) NT1W82DG CDS 5 CDS A
ABM CDS 5B (J10) NT1W82DG CDS 5 CDS B
ABM CDS 6A (J11) NT4K82DB CDS 6 CDS A
ABM CDS 6B (J12) NT4K82DB CDS 6 CDS B
ABM CDS 7A (J13) NT4K82DA CDS 7 CDS A
ABM CDS 7B (J14) NT4K82DA CDS 7 CDS B
Miscellaneous (side interconnect left)
ABM CDS MTA (J01) MTA (NT1W86NB) CDS 1 MTA (IN)
ABM LCAP 2 (J02) LCAP p/o LCAP shelf
ABM LCAP 1 (J03) LCAP p/o LCAP shelf
ABM OW EXT. (J04) Orderwire Extension
(NT1W85TA)
VF cross-connect Customer
assigned
ABM CU IF (J05/T1) High Temp return
(NT1W82FA)
High Temp sensor
ABM CU IF (J05/T2) High Temp
(NT1W82FA)
High Temp sensor
ABM CU IF (J05/O1W) Fan alarm return
(NT1W82FA)
BBP FAN Pin 2
—continued—
