Cabinet and equipment wiring and cabling 13-81
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Table 13-23 shows the power cabling and wiring information for the
S800A cabinet.
Table 13-23
AC/DC power cabling and wiring
From
Location Terminal Identification
To
Location Terminal
AC outlet box Rectifier 1 Rectifier shelf Rectifier 1 Rectifier 1
AC outlet box Rectifier 2 Rectifier shelf Rectifier 2 Rectifier 2
AC outlet box Rectifier 3 Rectifier shelf Rectifier 3 Rectifier 3
AC outlet box EMI #1 Load (BK) Rectifier 1 Rectifier shelf Position 1 (L1)
AC outlet box EMI #1 Load (RED) Rectifier 1 Rectifier shelf Position 1 (L2)
AC outlet box EMI #2 Load (BK) Rectifier 2 Rectifier shelf Position 2 (L1)
AC outlet box EMI #2 Load (RED) Rectifier 2 Rectifier shelf Position 2 (L2)
AC outlet box EMI #3 Load (BK) Rectifier 3 Rectifier shelf Position 3(L1)
AC outlet box EMI #3 Load (RED) Rectifier 3 Rectifier shelf Position 3 (L2)
AC outlet box EMI #1 Load (G) Rectifier shelf Frame ground
AC outlet box EMI #2 Load (G) Rectifier shelf Frame ground
AC outlet box EMI #3 Load (G) Rectifier shelf Frame ground)
DC distribution BIP -48V (BR1) -48V (NT1W87DA) BIP Batt.1/Ret.1
DC distribution BIP -48V (BR2) -48V (NT1W87DA) BIP Batt.2/Ret.2
DC distribution BIP -48V (BR3) -48V (NT1W87DA) BIP Batt.3/Ret.3
DC distribution BIP -48V (BR4) -48V (NT1W87DA) BIP Batt.4/Ret.3
DC distribution Batt.1 Battery 1
(NT1W84CA)
BBP A (Bat.1)
DC distribution Batt.2 Battery 2
(NT1W84CA)
BBP B (Bat.2)
DC distribution RECT (-48V) RECT 1 -48V Rectifier 1 -48V
DC distribution REPEATER DSX/RPTR 1 -48V
(NT1W84DA)
Repeater 1 Pin 1 (-48 A)
BBP B1 Repeater 2 power
(NT1W84DB)
Repeater 2 Pin 1 (-48 A)
