5.4.2 Manual paper insertion after a paper jam
114 A29246-X20-X-4-7680 / fa502_pinfed.fm
7. Cut paper in the input tray in the paper
stack area or at a negative (>) fold for
an external paper feed.
8. Remove paper from the entire paper path, including jammed paper, from the stacker
and the fuser station.
9. Only for external paper feed:
Guide the paper through the swing as
shown.
Proceed as follows:
