5.4.2 Manual paper insertion after a paper jam
A29246-X20-X-4-7680 / fa502_pinfed.fm 115
10. Hold the paper to the left at the first fold
and with the first and second page
folded up (i.e. with the first fold to the
right, first page underneath) push it
into the paper transporter.
11. Push the paper web through the paper
transporter until the paper web has left
the fuser station and the paper length
reaches the stacker floor.
Proceed as follows:
