5.4.2 Manual paper insertion after a paper jam
116 A29246-X20-X-4-7680 / fa502_pinfed.fm
12. Insert the paper web in the upper
tractors in such a way that the pins
protrude from the paper tractor holes.
Close both tractor doors.
13. Swivel the rocker upwards. The paper
is now automatically advanced.
14. Swivel the lever to the right. The lower
tractor doors are now closed.
Proceed as follows:
