6.3 Cleaning the paper path
182 A29246-X20-X-4-7680 / fa602_pinfed.fm
9. Swivel down the paper transporter by
the handle to the stop point.
10. When doing so, ensure that the locking
lever is engaged on the conveyor.
11. With the vacuum cleaner, vacuum the
toner, dust and paper particles from
the paper transporter and
environment.
Proceed as follows:
