6.3 Cleaning the paper path
186 A29246-X20-X-4-7680 / fa602_pinfed.fm
22. Press pressure pins inwards to lock.
23. Only for printing systems with heated
preheating saddle:
Open cover above the preheating
saddle.
Caution
Danger of burning when touching the hot preheating saddle.
Do not touch the hot preheating saddle.
24. Clean the suction slots of the
preheating saddle with a brush and a
vacuum cleaner.
Proceed as follows:
