6.5 Cleaning the fuser station
194 A29246-X20-X-4-7680 / fa603.fm
12. Press against pressure pin and swivel
out the waste collector.
13. Check the waste collector.
Important
Do not damage the cleaning plate.
14. Remove dirt from the cleaning plate with the paper cutter.
15. If it is over half filled with dirt, insert a new waste collector (see section 7.3.10
Replacing the waste collector, page 326).
Proceed as follows:
