6.5 Cleaning the fuser station
A29246-X20-X-4-7680 / fa603.fm 193
9. Swing the active filter unit back by the
handle until it reaches the stop point.
Caution
There can be a high build-up of static charge when vacuuming the toner spill.
Always use an industrial vacuum cleaner with a grounded suction tube, rubber
nozzle and filter set for fine dust. For larger quantities of toner spill (e. g. full bottle),
the industrial vacuum cleaner must be explosion-proof.
10. Vacuum the cleaning belt of dirt below
the contact surface with the fuser
roller.
11. Put on heat protection gloves (if you are not already wearing them).
Proceed as follows:
