6.5 Cleaning the fuser station
196 A29246-X20-X-4-7680 / fa603.fm
20. Turn pressure roller by hand and
check visually whether visible
damage, such as scratches, loosened
coating or blistering is present on the
surface. Replace the pressure roller if
damaged (see section 7.3.9 Replacing
the pressure roller, page 320).
21. Swivel on roller saddle.
22. Swivel on lower cover and lock.
Proceed as follows:
