6.5 Cleaning the fuser station
A29246-X20-X-4-7680 / fa603.fm 197
23. Swivel back waste collector and lock
by pressing knob.
24. Wipe off traces of oil in and around the
waste collector and around the stacker
cover area with a paper towel or cloth.
25. Swivel on oiling unit and tighten knob.
26. Close the front and side door of the fuser station.
27. Close cover hood.
Proceed as follows:
