6.6 Cleaning the soft fuser roller
A29246-X20-X-4-7680 / fa603.fm 201
9. Press the cloth lightly on to the fuser
roller and remove all toner residue with
circular movements.
10. Swivel the waste collector back into
position and lock with the knob.
11. Swivel on cleaning station again and
tighten knob.
12. Close the front and side door of the fuser station.
13. Close cover hood.
Proceed as follows:
3 of 4
