7.3.4.7 Replacing the discharge corotron (torn wire)
A29246-X20-X-4-7680 / fa703.fm 289
7.3.4.8 Complete corotron replacement >>> page 290
Proceed as follows:
1. Push new corotron cartridge into the
opening to the stop point.
2. Pull out handle of corotron mounting
and push towards PC drum until it
engages.
