7.3.5 Replacing the active filter
A29246-X20-X-4-7680 / fa703.fm 293
7. Lift up the active filter unit on the right
side using the handle and swivel out by
the rotary axle.
8. Turn the two knobs to the left and
swivel down filter frame.
9. Remove both old active filters.
Proceed as follows:
3 of 3
