7.3.7 Replacing the heater
A29246-X20-X-4-7680 / fa703.fm 305
11. Disconnect the heater connector plug
at the back of the printing system.
12. Remove cable from the cable clamp.
Caution
The components in the fuser station reach a surface temperature of approximately
230
o
C in operation.
If you touch them, you may burn yourself.
Put on heat protection gloves to continue working.
Proceed as follows:
