7.3.7 Replacing the heater
304 A29246-X20-X-4-7680 / fa703.fm
8. Move the temperature sensor to the
left.
The temperature sensor bar is now
swiveled up.
9. Loosen the heater connector plug on
the front side of the printing system
and straighten the cable .
10. Open the right door at the back of the printing system.
Proceed as follows:
