8.3 Clogged toner suction
344 A29246-X20-X-4-7680 / fa805.fm
b) Remove clogged toner from the toner feed hose
Proceed as follows:
1. If the printing system has not yet stopped, click the following button:
2. Open the center door at the back of the printing system.
3. Pull the container downwards with the
handle.
4. Move the lever upwards to swivel off
the drain head.
