8.3 Clogged toner suction
A29246-X20-X-4-7680 / fa805.fm 345
5. Turn the knob to the left to open the
door in front of the developer station.
Open the door in front of the developer
station.
6. Remove the toner feed hose (small
cross section) from the toner box
which is connected to the developer
station.
Caution
There can be a high build-up of static charge when vacuuming the toner spill.
Always use an industrial vacuum cleaner with a grounded suction tube, rubber
nozzle and filter set for fine dust. For larger quantities of toner spill (e. g. full bottle),
the industrial vacuum cleaner must be explosion-proof.
Proceed as follows:
