8.3 Clogged toner suction
346 A29246-X20-X-4-7680 / fa805.fm
7. Use a vacuum cleaner to vacuum the
clogged toner from the hose you have
just removed.
Also carefully vacuum accumulated
toner from the underside of the drain
head (above the toner bottle).
8. Re-affix the toner feed hose to the
toner box.
9. Close the door in front of the developer
station.
Turn the turning knob to the left.
Proceed as follows:
3 of 4
To Next Page
