Oki C911 - Paper Cassette Switches and Paper Size Correlation Table

45530603TH Rev.2
4-96
Oki Data CONFIDENTIAL
4. TROUBLESHOOTING PROCEDURE
(1) Source tray
Switch Part No. 2052000P4000
Model No: HS12-001
Size Bit No.
TRAY1
〜
5 1 2 3 4
No Cassette H H H H
A3 nobi,18" H H L L
17"(Tabloid) L H L L
A3 L H H L
B4 H H H L
Legal 14/13.5 H L H L
Legal 13 H L H H
A4 (SEF) L L L H
Letter (SEF) L L L L
Executive L L H L
B5 (SEF) L L H H
Letter (LEF) L H L H
A4 (LEF) H H L H
A5 H L L H
B5 (LEF) L H H H
A6 H L L L
SW push
:
L
4.7 Paper cassette switches and paper size correlation table
