Oki C911 Maintenance Manual

45530603TH Rev.2
5-40
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
Upper line of the display Lower line of the display
Details Memory
1: ****V -***V D.P +***V -**V Upper left: Standard CH voltage
Upper right: DB voltage at BG adjustment
Lower left: CH offset voltage when dirt is
detected
Lower right: CH shift value
SRAM
2: ****V -***V D.P +***V -**V Upper left: Standard CH voltage
Upper right: DB voltage at BG adjustment
Lower left: CH offset voltage when dirt is
detected
Lower right: CH shift value
SRAM
3: ****V -***V D.P +***V -**V Upper left: Standard CH voltage
Upper right: DB voltage at BG adjustment
Lower left: CH offset voltage when dirt is
detected
Lower right: CH shift value
SRAM
4: ****V -***V D.P +***V -**V Upper left: Standard CH voltage
Upper right: DB voltage at BG adjustment
Lower left: CH offset voltage when dirt is
detected
Lower right: CH shift value
SRAM
5: ****V -***V D.P +***V -**V Upper left: Standard CH voltage
Upper right: DB voltage at BG adjustment
Lower left: CH offset voltage when dirt is
detected
Lower right: CH shift value
SRAM
BG. SB HOSEI 1:+***V 2:+***V SB adjustment voltage by the auto B.G
adjustment
SRAM
3:+***V 4:+***V
5:+***V
BG. CH HOSEI 1:+***V 2:+***V CH adjustment voltage by the auto B.G
adjustment
SRAM
3:+***V 4:+***V
5:+***V
• Results will be stored as described in memory filed.
• The contents in SRAM are deleted when the test starts, and values detected at the normal
competition or until the apparatus stops due to errors are written.
5.3.2.8 Adjustment of Media Thickness Sensor
This self diagnosis is used for adjusting the media Thickness sensor.
Notes! Check the Zero point output of Media Thickness Sensor in advance.
①
Display the Paper thickness sensor output with 5.3.2.3 Switch Scan test.
Remove all papers at paper feed route as of now.
②
Check paper thickness sensor output is 260h to 300h or not.
③
If out of range, carry out a Zero point adjustment of Media Thickness Sensor.
For the adjustment, four sheets of a media whose Thickness(It is more desirable for measure
by micrometer) has been specified in advance are required. (Three sheets are required for
the adjustment and one sheet is required for the check after the adjustment.)
Media to be used and setting values
No. Type
Media Thickness
setting value
(Default)
Number of sheets
(Default)
Remarks
1 Media for sensitivity correction 6EH (110 µ m) 3
2 Media for checking 6EH (110 µ m) 1
The thickness of typify is refer to the following table.
Paper thickness change by lot and environment so that recommend to measure by
micrometer.
Media
name
OKI data
excellent
white
OKI data
excellent white
(Thick)
Data Copy HAMMERMILL
24lb
Mondi
Color Copy
100
3M CG3600
(OHP)
size A4 A4 A4 LT A4 A4
Thickness
(
μm
)
90 115 105 104 104 104
In order to execute this adjustment (MEDIA WT ADJUST PA), stack the above media in order
in advance (No.1 and No.2 in order from the above four sheets in total) and then set the
media on MPT.
