Oki C911 Maintenance Manual

45530603TH Rev.2
5-51
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
5.3.2.13 Self-diagnostic function setting
The self-diagnostic function setting is used for enabling or disabling the error detection by
sensors.
The detection can be enabled or disabled temporarily for troubleshooting research. Allowing
for setting engine operation options for which expert knowledge is required to be handled.
This self-diagnostic should be used carefully.
Be sure to restore the default settings of used options of the self-diagnostic.
1. Enter the self-diagnostic (Level1) mode and, until the following message
appears, press the MENU
or MENU button.
sensoR setting
2. Press the OK button. The following message appears. Press the MENU
or MENU
button until the option intended (refer to the table shown below)
appears.
toneR sensoR
enaBLe *
3. The setting on the lower display can be selected by pressing the OK button.
The MENU
button displays the next setting and the MENU button displays
the preceding setting.
4. Press the OK button while the desired setting is on the display. The setting is
stored in the EEPROM. The state is restored to the step 2.
5. Repeat steps 2 through 4 when necessary.
6. Press the BACK button to end the setting (except where not in the step 4) (the
state is restored to the step 1).
SENSOR SETTING Items
LCD Setting value Operation of the setting value Details
TONER
SENSOR
ENABLE Enables detection. Enables or disables toner
sensor operation.
DISABLE Disables detection.
WASTE TNR
SNS
ENABLE Enables detection. Enables or disables the waste
toner sensor
DISABLE Disables detection.
BELT UNIT
CHECK
ENABLE Enables checking. Enables or disables belt
installation checking operation.
DISABLE Disables checking.
ID UNIT
CHECK
ENABLE Enables checking. Enables or disables ID
installation checking operation.
DISABLE Disables checking.
REG
ADJUST
ERROR
ENABLE Stops Enables or disables the display
of errors in the auto color mis-
registration correction control
DISABLE Does not stop
DRUM OVER
LIFE
Stop Does not extend the life duration Enables or disables the life
extension processing
CONTINUANVE Extends the life duration
WR POINT
REV
00H
〜
FFH A correction value. Adds a correction value for the
default writing point.
Default is in hatched area.
