45530603TH Rev.2
5-28
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
5.3.2.5 Test print
The test printing is used for printing test patterns stored in the PU. Other patterns are stored
in the controller.
This test print cannot be used to check the print quality.
Diagnosis for the abnormal print image should be performed in accordance with Chapter 7.
1. Enter the self-diagnostic mode (level 1) and, until TEST PRINT appears on the
upper display, press the MENU
or MENU button. Then press the OK button.
(The MENU
button displays the next test option and the MENU button
displays the preceding test option)
2. A setting option used only in test printing appears on the lower display. Press
the MENU
or MENU button until the option to select appears. Then press the
ENTER button. (The MENU
button displays the next option and the MENU
button displays the preceding option) (Go to step 4 when set to its default, the
option does not need to be set).
test PRint
test PatteRn
3. Keep pressing the MENU , MENU key, and press the OK button at the
menu item set by step 2. Then, the setting item is displayed in the upper row of
display area, and the setting value is displayed in the lower row of display area.
Pressing the MENU
button displays the next setting and pressing the MENU
button displays the preceding setting (the setting last displayed takes effect.
By pressing the BACK button, the setting is accepted, step 2 being restored.
Repeat step 3 when necessary.
test PatteRn
1
4. By pressing OK button under the condition where “PRINT EXECUTE” is
displayed in the lower line of the display after making a setting, the test print is
executed based on the value set in the step 2 to 3.
test PRint
PRint eXecUte
Pressing the CANCEL button stops the test print.
If an error is detected at the start of the test print or when executing the test
print, the error is displayed on the panel and the test print is canceled.
Display Settings Default Function
PRINT
EXECUTE
- - Starts printing with the press of the OK button
Ends printing with the press of the CANCEL
button.
TEST
PATTERN
0
〜
15 0 0: Prints a blank page.
1 to 7: pattern printing (See the table 5-6)
8 to 15: Print a blank page.
TEST
CASSETTE
TRAY1 TRAY1 Select the paper feed source.
Not displayed when the tray 2 is not installed.
Not displayed when the tray 3 is not installed.
Not displayed when the tray 4 is not installed.
Not displayed when the tray 5 is not installed.
TRAY2
TRAY3
TRAY4
TRAY5
MPT
PAGE 0000 0000 Sets the number of test copies printed
STATION S1 OFF Sets a station to be used
OFF: Not used
ON: Used
S2 ON
S3 ON
S4 ON
S5 ON
MEDIA MEDIA TYPE PLAIN PAPER Changes the setting of a TRAY selected in
TEST CASSETTE. See the table 5-7.
If CUSTOM SIZE is not selected in MEDIA
SIZE, CUSTOM LEN, and CUSTOM WIDTH
are not displayed.
If CU printing is performed form the
corresponding tray before executing the test
print, the default is a value specified by CU.
MEDIA WEIGHT MEDIUM
LIGHT
MEDIA SIZE A4(LEF)
CUSTOM LEN 0210
CUSTOM WIDTH 0297
MEDIA CHECK ENABLE Sets ENABLE/ DISABLE of the paper size
check.
OUTPUT
BIN
FACE DOWN FACE DOWN Selects the output bin.
FACE DOWN/ FACE UP
FACE UP
To Next Page
