45530603TH Rev.2
5-57
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
5.5 Manual density adjustment setting
This printer is shipped with the auto density adjustment mode enabled. When the
mode is disabled by a user, the printer may print density out of adjustment while being used.
Manually perform density adjustment setting when the printer prints an improper density.
Note! The setting must be performed with the printer in a static state. Do not perform
it while the printer warms up.
(1) Press the MENU
or MENU button more than one time. Press the OK button
when Calibration appears.
(2) Press the MENU
or MENU button to select Adjust Density Execute. Press the
OK button.
(3) Press the OK button.
Auto density adjustment starts, the operation panel display providing a message
stating that density is being adjusted.
To Next Page
