Oki C911 Maintenance Manual

45530603TH Rev.2
5-27
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
Panel Display Driven Unit
Conditions for Driving Limitation
T2 LIFT_UP MOTOR Tray 2 lift-up motor The tray is removed.
T2 HOPPING MOTOR Tray 2 hopping motor
Tray 2 hopping clutch
The tray is removed.
T2 FEED CLUTCH Tray 2 hopping motor
Tray 2 regist clutch
T3 LIFT_UP MOTOR Tray 3 lift-up motor The tray is removed.
T3 HOPPING MOTOR Tray 3 hopping motor
Tray 3 hopping clutch
The tray is removed.
T3 FEED CLUTCH Tray 3 hopping motor
Tray 3 regist clutch
T4 LIFT_UP MOTOR Tray 4 lift-up motor The tray is removed.
T4 HOPPING MOTOR Tray 4 hopping motor
Tray 4 hopping clutch
The tray is removed.
T4 FEED CLUTCH Tray 4 hopping motor
Tray 4 regist clutch
T5 LIFT_UP MOTOR Tray 5 lift-up motor The tray is removed.
T5 HOPPING MOTOR Tray 5 hopping motor
Tray 5 hopping clutch
The tray is removed.
T5 FEED CLUTCH Tray 5 hopping motor
Tray 5 regist clutch
DUPLEX SOLENOID Duplex separator solenoid Rail unit is closed.
2PASS SOLENOID 2-Pass solenoid Duplex unit is installed and
rail unit is closed.
DUPLEX ENTRY
MOTOR
DUPLEX motor 1 Duplex unit is installed and
rail unit is closed.
DUPLEX FEED
MOTOR
DUPLEX motor 1 (Reverse
rotation)
DUPLEX motor 2
Duplex unit is installed and
rail unit is closed.
2PASS FEED
MOTOR
DUPLEX motor 1
DUPLEX motor 2
2-Pass solenoid
Duplex unit is installed and
rail unit is closed.
DUPLEX REG
CLUTCH
Feed motor
DUPLEX hopping clutch
Rail unit is closed.
DUPLEX FAN DUPLEX FAN Duplex unit is installed and
rail unit is closed.
(Note1) Display "FAILD" when four color model.
Note!
①
Display while ID UP/DOWN is in progress
MotoR & cLUtcH test
iD UP/DoWn ***
***: Identifies the number of times
②
Display when the REGIST SHUTTER ON LINE button is pressed
MotoR & cLUtcH test
sHt **********
**********: Identifies the number of times
③
Display while FUSER RLS is in progress
MotoR & cLUtcH test
RLs *******
*******: Identifies the number of times
④
Display while TR2 POS ADJ is in progress
MotoR & cLUtcH test
tR2 Pos aDJ ***
***: Identifies the number of times
⑤
Display while JOB OFFSET ON LINE button is pressed.
MotoR & cLUtcH test
JoB oFFset *******
*******: Identifies the number of times
