Oki C911 Maintenance Manual

45530603TH Rev.2
6-42
Oki Data CONFIDENTIAL
6. REPLACEMENT OF PARTS
⑦
-1 45180501PA Case-Cassette-Assy
⑦
-2 45180501PA Case-Cassette-Assy
Class B
Apply a normal amount of MOLYKOTE
In the state the Gear-Lift-Up is stayed at the bottom,
put the grease to the range of turning the tooth
of Gear-Coupling.
Class B
Apply a normal amount of MOLYKOTE
In the state the Gear-Lift-Up is stayed at the top,
put the grease to the tooth of it on the portion of
engaging with the Gear-idle, and rotate one revolution of it.
Gear-Lift-Up
Gear-Idle
Coupling-LiftUP
Class C
Apply a normal amount
of MOLYKOTE(EM30LP
)
to the all over the shaft
Plate-LU-Caulking
