1. CONFIGURATION
Ta bl e 1 -1 P CB l is t o f C 911/ C 93 1/ C 9 41 / ES 94 11 / ES 94 31 /E S9 54 1
No Name Purpose Remarks
1 F1Y Printer controller (PU/CU) For five-color models
2 F1Y-2 Printer controller (PU/CU) For four-color models
3 F1X Spot color control Used for five-color models only.
4 F1D Driver relay For five-color models
5 F1D-2 Driver relay For four-color models
6 F1T-1 Duplex unit control
7 F1T-2 Optional tray units control
8 F1P or F1A Control panel control
9 F1E External LED
10 F1G Tag terminal
11 F1H Head power relay
12 F1K Cassette sensor relay Common to the main unit and option trays
13 F1L EJ-Rail unit relay
14 F1N Toner-low sensor, Waste-toner-full sensor
15 F1S MPT relay
16 F1W Soft switch
17 AHV-1 High-voltage power supply For five-color models
18 AHV-2 High-voltage power supply For four-color models
19 PWR unit-ACDC Switch Low-voltage power supply
20 AHR High-voltage relay
21 F1B Belt thermistor relay Consisted in the belt unit
22 MFH Environmental sensor
