4. TROUBLESHOOTING PROCEDURE
(10) Set to the output unit and attach the screw.
Note! Pay attention to don't drop into the printer when attach the screws.
①
②
②
①
②
①
(11) Hold the fuser unit’s handle with both hands and set to the output unit.
(12) Push down the fuser unit’s lock lever (blue).
(13) If paper is set in the MP tray, remove it and close the tray.
