Chapter 8
92
Figure 8-3 Removing the lithium-ion battery
3. Insert a new battery. Make sure that the groove on the battery is aligned with the
small edge inside the battery compartment.
4. Close the battery compartment door.
The batteries are recharged inside the OmniScan MX when it is connected to a DC
power adaptor. Connecting an adaptor automatically starts the recharging process.
The batteries can also be recharged using an optional external charger.
8.2.5 Battery Charging
To charge the OmniScan MX batteries
Connect the OmniScan MX to a proper DC power adaptor.
Battery charging is performed as follows:
• When the OmniScan MX is turned off:
When the OmniScan MX is connected to a proper DC power source and is
turned off, it will automatically recharge any battery with less than 85 %
remaining charge, starting with the weakest battery (if the recharge
conditions are met).
Lithium-ion
battery
Cloth tab
Battery
compartment
door
