OMNI-M2-PA1664/16128/32128/32128PR Module Specifications
187
Figure N-4 Module with PA connector cap
Before using a phased array probe that is not equipped with an EZ Latch connector,
remove the anchor base, which is secured by two screws.
You can also attach accessories to these acquisition modules using the fastening holes
(see Figure N-5 on page 188).
