K.3 Data Specifications
This section details the data specifications of processing, TCG, and storage (see
Table 61 on page 170).
Table 61 Data specifications
Processing
Number of data points Up to 8000
Real-time averaging 2, 4, 8, and 16
Rectification RF, full wave, half wave +, half wave –
Filtering Low-pass (adjusted to probe frequency),
digital filtering (bandwidth, frequency
range)
Video filtering Smoothing (adjusted to the probe frequency
range)
Programmable TCG
Number of points 16: One TCG (time-corrected gain) curve
per channel for focal laws
Storage
A-scan recording 6000 A-scans per second (512-point, 8-bit
A-scan)
C-scan recording I, A, B, up to 10 kHz
Maximum file size Limited to available internal flash memory:
300 MB
