Olympus OmniScan MX2 - ECT Acquisition Module Specifications

DMTA-20015-01EN [U8778402], Rev. J, January 2014
Appendix L 174
L.5 ECT Acquisition Module Specifications
This section covers the ECT acquisition module specifications, and includes the
general specifications of the module, in addition to specifications applicable to the
generator and receivers.
5ANGDGround
6ANGDGround
7 GEN50_2 Main generator 50/100 Ω Termination #2
8 GEN0° Main generator #1 direct output
9 GEN180° Main generator #2 direct output
10 −VDC_DRV_P External MUX power supply –8/–10 V 500 mA
11 IN1+ Input 1 positive
12 IN1− Input 1 negative
13 IN2+ Input 2 positive
14 IN2− Input 2 negative
15 IN3+ Input 3 positive
16 IN3− Input 3 negative
17 IN4+ Input 4 positive
18 IN4− Input 4 negative
19 +VDC_DRV_P External MUX power supply +8/+10 V 500 mA
Table 62 Pinout for the
4CH connector [OMNI-M-ECT4 module] (continued)
Pin Signal Description Current
