Appendix E: OMNI-M-PA1616M and OMNI-M-PA1664M
Module Specifications
To reduce the risk of electric shock, avoid touching the inner conductor of the BNC (or
LEMO) connectors. Up to 200 V can be present on the inner conductor. The warning
symbol near the BNC connectors signals this electric shock risk.
The OMNI-M-PA1616M module is compatible with the OmniScan MX only.
This appendix outlines the technical specifications for OmniScan PA acquisition
module models OMNI-M-PA1616M and OMNI-M-PA1664M (see Figure E-1 on
page 144).
