Olympus OmniScan MX2 - Acquisition Indicator Light; Table 18 Power Indicator Light Statuses; Table 19 Acquisition Indicator Light Statuses

DMTA-20015-01EN [U8778402], Rev. J, January 2014
Overview of the Equipment 81
7.1.9.3 Acquisition Indicator Light
The acquisition indicator light is located to the left of the Start/Stop key ( ). The
color of this light indicates the OmniScan MX operating mode (see Table 19 on
page 81).
If an acquisition module is removed while the OmniScan MX is turned on, the
keypad, power, and acquisition indicator lights flash red for a few seconds, and then
the unit automatically shuts down to prevent damage to the internal circuits.
Table 18 Power indicator light statuses
Off The OmniScan MX is turned off.
Green The instrument is ready (start-up
complete).
Orange Battery charging is complete.
Flashing orange/green The OmniScan MX is shut off. Battery A is
charging.
Flashing orange/red The OmniScan MX is shut off. Battery B is
charging.
Flashing red Critical factor (temperature, very weak
battery, etc.)
Table 19 Acquisition indicator light statuses
Off Acquisition mode
Flashing orange Paused analysis mode
