7.1.9.4 Alarm Indicator Lights
There are three alarm indicator lights (numbered 1, 2, and 3) located on the upper right
corner of the OmniScan MX. These lights only flash one color (red) and indicate the
trigger status of their respective alarms (set by the software).
For more details about the alarm indicator lights, refer to the OmniScan software
user’s manuals.
7.2 Right Side Panel
The right side panel of the OmniScan MX (see Figure 7-3 on page 83) contains various
input and output ports.
