H.3 Data Specifications
This section details the data specifications of processing, TCG, and storage (see
Table 52 on page 158).
Table 52 Data specifications
Processing
Number of data points Up to 8000
Real-time averaging 2, 4, 8, and 16
Rectification RF, full wave, half wave +, half wave –
Filtering Low-pass (adjusted to probe frequency),
digital filtering (bandwidth, frequency
range).
Video filtering N/A
Programmable TCG
Number of points 16: One TCG (time-corrected gain) curve
per channel for focal laws
Storage
A-scan recording 6000 A-scans per second (512-point, 8-bit
A-scan)
C-scan recording I, A, B, up to 10 kHz
Maximum file size Limited to available internal flash memory:
OmniScan MX: 180 MB (or 300 MB
optional)
OmniScan MX2: 300 MB
