DMTA-20015-01EN [U8778402], Rev. J, January 2014
OMNI-M2-UT-2C Module Specifications
193
Appendix O: OMNI-M2-UT-2C Module Specifications
• To reduce the risk of electric shock, avoid touching the inner conductor of the
LEMO connectors. Up to 340 V can be present on the inner conductor of the UT
connectors. The warning symbol near the LEMO connectors signals this electric
shock risk (see Figure O-1 on page 193).
• Reinforced insulation must be provided for the probes connected to the module.
Figure O-1 Module side view
Warning symbol
UT connectors
