Olympus OmniScan MX2 - Appendix M: OMNI-M-ECA4-32 Module Specifications; ECA Acquisition Module Description

DMTA-20015-01EN [U8778402], Rev. J, January 2014
OMNI-M-ECA4-32 Module Specifications 177
Appendix M: OMNI-M-ECA4-32 Module Specifications
The OMNI-M-ECA4-32 module is compatible with the OmniScan MX only.
This appendix presents eddy current array (ECA) acquisition module model
OMNI-M-ECA4-32, which can be used with the OmniScan MX unit.
M.1 ECA Acquisition Module Description
The ECA acquisition module (see Figure M-1 on page 178) is designed for durability
and simplicity. You can use the module to perform eddy current array or conventional
eddy current inspections.
